The main characteristics of the digital power chip are as follows:

• High operating frequency of 200MHz

• High reliability Flash memory, supporting ECC (Error Correction Code) and storage encryption.

• Large SRAM capacity of 196KB, strong reliability, supporting parity and ECC

• Abundant timer resources, including 1 high-precision timer (125ps accuracy), 3 advanced timers (5ns accuracy), and 10 general-purpose timers (5ns or 10ns accuracy)

• 3 U(S)ART TX and RX pins support full pin mapping, facilitating customer pin allocation.

• CAN-FD pins support full pin mapping, facilitating customer pin allocation.

• Fast ADC sampling speed of 4.7Msps, supporting both single-ended and differential modes.

• High-performance operational amplifiers, supporting single-ended and differential modes, with a GBW of 40MHz, SR of 20V/μs (single-ended mode), and SR of 40V/μs (differential mode)

• Cordic supports integer and floating-point operations.

• Strong EFT performance: power supply +/-4kV, Class A; IO +/-2kV, Class A

• Strong live ESD performance: power/ground +/-10kV, Class A; IO +/-1.5kV, Class A

Recommended Models:

• N32H474
